| System |
| Main Processor |
Multi-core embedded processor |
| Operating System |
Embedded LINUX |
| Perimeter Protection |
| Performance |
16 channel, 10 IVS rules for each channel |
| Object classification |
Human/Vehicle secondary recognition for tripwire and intrusion |
| AI Search |
Search by target classification (Human, Vehicle) |
| Face Recognition |
| Performance |
Max 24 face pictures /sec processing (modeling and comparing)
4 channel video stream face recognition / 16 channel picture stream face recognition ( with FD camera) |
| Stranger Mode |
Detect strangers' faces(not in device's face database).Similarity threshold can be set manually. |
| AI Search |
Up to 8 target face images search at same time, similarity threshold can be set for each target face image. |
| Database Management |
Up to 20 face databases with 100,000 face images in total. Name, gender, birthday, nationality, address, ID information can be added to each face picture. |
| Database Application |
Each database can be applied to video channels independently. |
| Trigger Events |
Buzzer, Voice Prompts, Email, Snapshot, Recording, Alarm Out, PTZ Activation, etc. |
| Metadata |
| Face |
Gender, age, glasses, beard, mask. |
| Vehicle |
Vehicle color, vehicle model, vehicle logo, plate color, vehicle decorations, call, seatbelt. |
| Human Body |
Tops style,tops color,bottom style,bottom color, hat, bag. |
| Non-motor Vehicle |
Type, color, people number. |
| AI Search |
Support search target video by metadata. |
| Audio and Video |
| IP Camera Input |
16 Channel |
| Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
HDMI/VGA: 3840 × 2160 , 1920 × 1080 , 1280 × 1024, 1280 × 720 , 1024 × 768 |
| Decoding Capability |
4-ch@8MP(30fps), 16-ch@1080P(30fps) |
| Multi-screen Display |
1/4/8/9/16 |
| Recording |
| Bandwidth |
320Mbps (160Mbps when AI function enabled) |
| Compression |
Smart H.265+/H.265/Smart H.264+/H.264/MJPEG |
| Resolution |
16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1 etc. |
| Record Mode |
Manual, Schedule (Continuous, MD(Motion Detection) , Alarm, IVS) |
| Record Interval |
1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Video Detection and Alarm |
| Trigger Events |
Alarm Out, Video Push, Email, Recording, PTZ, Tour, Snapshot, Voice Prompt, Buzzer and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Scene Change |
| Alarm input |
4 Channel |
| Relay Output |
2 Channel |
| Playback and Backup |
| Sync Playback |
1/4/9/16 |
| Search Mode |
Time /Date, Alarm, MD and Exact Search (accurate to second) |
| Backup Mode |
USB Device/Network |
| Third-party Support |
| Third-party Support |
Arecont Vision, Airlive, AXIS, Canon, Dynacolor, JVC, LG, Panasonic, Pelco, PSIA, Samsung, Sanyo, Sony, Watchnet and more |
| Network |
| Interface |
1 RJ-45 Ports (10/100/1000Mbps) |
| PoE |
16 ports (IEEE802.3af/at) 1-8 ports support ePoE & EoC |
| Network Function |
HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support IP camera, DVR, NVS, etc.), P2P |
| Max. User Access |
128 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF 2.4, SDK, CGI |
| Storage |
| Internal HDD |
2 SATA III Ports, Up to 8 TB capacity for each HDD |
| eSATA |
N/A |
| Auxiliary Interface |
| USB |
2 USB Ports (1 Rear USB 3.0 , 1 Front USB 2.0 ) |
| RS232 |
1 Port, for PC Communication and Keyboard |
| RS485 |
1 Port, for PTZ Control |
| Electrical |
| Power Supply |
Single, AC100V ~ 240V, 50 ~ 60 Hz |
| Power Consumption |
NVR: PoE: Max 25.5W for single port 130W total rated power, 80% control for protection |
| Fan |
Smart fan, automatically adjust running speed |
| Environmental |
| Operating Conditions |
-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions |
-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH |
| Construction |
| Dimensions |
1U, 375mm x 327.3mm x 53mm ; (14.8" x 12.9" x 2.1") |
| Net Weight |
2.70kg (6.0 lb) (without HDD) |
| Gross Weight |
4.00kg (8.8 lb) (without HDD) |
| Certifications |
| CE |
EN55032, EN55024, EN50130-4, EN60950-1 |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| UL |
UL 60950-1 |
