Dahua IP 2x4MP IP67 IR 2.8mm Multi-Sensor Panoramic Bullet TIOC Duo Camera
- Outputs 180° wide angle splicing image.
- Outputs max. 8 MP (4096 × 1860)@20 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in IR LED and warm light, the max. IR illumination distance is 25 m and warm light distance is 20 m.
- 12 VDC/PoE power supply, easy for installation.
- One-tap arming/disarming through alarm input
- Sound and light alarm (red and blue lights)
- EPTZ: Enlarge and track the targets of intelligent alarms.
- SMD 4.0.
- IP67 protection.
Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.
Series Overview
Dahua WizSense 3 Series Network Camera greatly saves on bandwidth and storage space through its AI Coding technology. Driven by its advanced deep learning algorithms, the camera supports intelligent functions such as perimeter protection, smart motion detection (SMD), Quick Pick, making it easy and convenient to use. Starlight technology and its large aperture lens also allow the camera to produce clear, vivid images even in poor lighting conditions
Functions
SMD 4.0
Dahua Smart Motion Detection technology works with intelligent algorithms to classify targets that trigger motion detection alarms. It filters out objects that are not targets, such as small and large animals, to avoid triggering false alarms. With an AI NVR, Quick Pick technology becomes available, allowing you to easily search for and pick out human and vehicle targets from SMD event videos, prioritizing the highest matches.
EPTZ
With advanced target detection and tracking algorithms, Dahua EPTZ technology can simultaneously zoom in and track multiple humans and vehicles that trigger alarms. It provides rich details and a panoramic view at the same time.
Siren and Light Active Deterrence
Dahua siren and light active deterrence network camera supports the light alarm and voice alarm when perimeter event occurs, to realize the deterrence and effective intervention. The camera is built in multiple voices for selection, and supports customized voice importing
Smart Dual Light
Dahua Smart Dual Light technology adopts smart algorithm to detect targets. Usually, the IR illuminator is on at night; when the target appears in the monitoring area, the warm light is on, and the camera records the full-color video and information of key events. That is, the camera links snapshot and video with full-color image. When the target is out of the monitoring area, the warm light is off and the IR illuminator is on, which reduces light pollution efficiently.
One-tap Disarming
Dahua One-tap Disarming function, which is convenient and easy for operation, is the switch for event linkage. Customers can close and recover event linkage through mobile App, which meets multi-scenarios needs.
Protection (IP67, wide voltage)
IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.
Cyber Security
Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage. These technologies improve the camera's defense against external cyber threats and prevent malicious programs from compromising the device.
Case Studies | |
---|---|
IPCPFW3849SA180 - Quick Guide | Datasheets |
Dahua IP 2x4MP IP67 IR 2.8mm Multi-Sensor Panoramic Bullet TIOC Duo Camera - Datasheet | Product Manuals |
Dahua IP 2x4MP IP67 IR 2.8mm Multi-Sensor Panoramic Bullet TIOC Duo Camera - Product Manual |
Brand: Dahua |
Code: IPCPFW3849SA180
APN: 6923172571953 |
Supplier Code: 1.0.01.04.41928-0001
Brand: Dahua |
Code: IPCPFW3849SA180
APN: 6923172571953 |
Supplier Code: 1.0.01.04.41928-0001
At a glance
- Outputs 180° wide angle splicing image.
- Outputs max. 8 MP (4096 × 1860)@20 fps.
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in IR LED and warm light, the max. IR illumination distance is 25 m and warm light distance is 20 m.
- 12 VDC/PoE power supply, easy for installation.
- One-tap arming/disarming through alarm input
- Sound and light alarm (red and blue lights)
- EPTZ: Enlarge and track the targets of intelligent alarms.
- SMD 4.0.
- IP67 protection.
