Dahua IP 2x4MP IP67 IR 2.8mm Multi-Sensor Panoramic Turret TIOC Duo Camera

Dahua IP 2x4MP IP67 IR 2.8mm Multi-Sensor Panoramic Turret TIOC Duo Camera

  PRODUCT ENQUIRY
  • Outputs 180° wide angle splicing image.
  • Outputs max. 8 MP (4096 × 1860)@20 fps.
  • H.265 codec, high compression rate, ultra-low bit rate.
  • Built-in IR LED and warm light, the max. IR illumination distance is 25 m and warm light distance is 20 m.
  • 12 VDC/PoE power supply, easy for installation.
  • One-tap arming/disarming through alarm input
  • Sound and light alarm (red and blue lights)
  • EPTZ: Enlarge and track the targets of intelligent alarms.
  • SMD 4.0.
  • IP67 protection.

Brand: Dahua Code: IPCPDW3849PA180
APN: 6923172571793   |    Supplier Code:
Supplier Description: IPC-PDW3849-A180-AS-PV

Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

Series Overview

Dahua WizSense 3 Series Network Camera greatly saves on bandwidth and storage space through its AI Coding technology. Driven by its advanced deep learning algorithms, the camera supports intelligent functions such as perimeter protection, smart motion detection (SMD), Quick Pick, making it easy and convenient to use. Starlight technology and its large aperture lens also allow the camera to produce clear, vivid images even in poor lighting conditions

Functions

SMD 4.0

Dahua Smart Motion Detection technology works with intelligent algorithms to classify targets that trigger motion detection alarms. It filters out objects that are not targets, such as small and large animals, to avoid triggering false alarms. With an AI NVR, Quick Pick technology becomes available, allowing you to easily search for and pick out human and vehicle targets from SMD event videos, prioritizing the highest matches.

EPTZ

With advanced target detection and tracking algorithms, Dahua EPTZ technology can simultaneously zoom in and track multiple humans and vehicles that trigger alarms. It provides rich details and a panoramic view at the same time.

Siren and Light Active Deterrence

Dahua siren and light active deterrence network camera supports the light alarm and voice alarm when perimeter event occurs, to realize the deterrence and effective intervention. The camera is built in multiple voices for selection, and supports customized voice importing

Smart Dual Light

Dahua Smart Dual Light technology adopts smart algorithm to detect targets. Usually, the IR illuminator is on at night; when the target appears in the monitoring area, the warm light is on, and the camera records the full-color video and information of key events. That is, the camera links snapshot and video with full-color image. When the target is out of the monitoring area, the warm light is off and the IR illuminator is on, which reduces light pollution efficiently.

One-tap Disarming

Dahua One-tap Disarming function, which is convenient and easy for operation, is the switch for event linkage. Customers can close and recover event linkage through mobile App, which meets multi-scenarios needs.

Protection (IP67, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% (for some power supplies) input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

Cyber Security

Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage. These technologies improve the camera's defense against external cyber threats and prevent malicious programs from compromising the device.

  • Outputs 180° wide angle splicing image.
  • Outputs max. 8 MP (4096 × 1860)@20 fps.
  • H.265 codec, high compression rate, ultra-low bit rate.
  • Built-in IR LED and warm light, the max. IR illumination distance is 25 m and warm light distance is 20 m.
  • ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
  • WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
  • Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD card; built in dual Mic; built in speaker, support two-way talk.
  • 12 VDC/PoE power supply, easy for installation.
  • IP67 protection.
  • Sound and light alarm (red and blue lights)
  • EPTZ: Enlarge and track the targets of intelligent alarms.
  • SMD 4.0.
  • One-tap arming/disarming through alarm input
Camera
Image Sensor Dual 1/2.7" CMOS
Max. Resolution 4096 (H) × 1860 (V)
ROM 128 MB
RAM 1 GB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination

0.005 lux@F1.4 (Color, 30 IRE)

0.0005 lux@F1.4 (B/W, 30 IRE)

0 lux (Illuminator on)

S/N Ratio >56 dB
Illumination Distance

Up to 25 m (82.02 ft) (IR LED)

Up to 20 m (65.62 ft) (Warm light)

Illuminator On/Off Control Auto; Manual
Illuminator Number 2 (IR LED); 2 (Warm light)
Angle Adjustment

Pan: 0°–360°

Tilt: 0°–77°

Rotation: 0°–360°

Lens
Lens Type Fixed-focal
Lens Mount M12
Focal Length 2.8 mm
Field of View Horizontal: 180°; Vertical: 86°
Max. Aperture  F1.4
Iris Control  Fixed
Close Focus Distance  0.8m (2.62 ft)
DORI Distance
Lens Detect Observe Recognize Identify
2.8 mm 50.6 m (166.01 ft) 20.2 m (66.27 ft) 10.1 m (33.14 ft) 5.1 m (16.73 ft)
Intelligence
IVS (Perimeter Protection) Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
SMD SMD 4.0
Quick Pick With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events.
Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
EPTZ Enlarge and track the targets of intelligent alarms
Video
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec

Smart H.265+;

Smart H.264+

AI Coding

AI H.265;

AI H.264

Video Frame Rate

Main stream: 4096 × 1860@(1–20 fps )

Sub stream: 1200 × 530@(1–20 fps)

Third stream: 1920 × 860@(1–20 fps)

*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Stream Capability 3 streams
Resolution 4096 × 1860; 3632 × 1632; 3040 × 1368; 1200 × 530; 1920 × 860; 960 × 432
Bit Rate Control CBR/VBR
Video Bit Rate

H.264: 6 kbps –16384 kbps

H.265: 6 kbps –16384 kbps

Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
Scene Self-adaptation (SSA) Yes
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Auto
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Privacy Masking 4 areas
Defog Yes
Audio
Built-in MIC Yes, built-in dual Mic
Built-in speaker Yes, built-in speaker
Audio Compression G.711a; G.711Mu; PCM; G.726; G.723
Alarm
Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene chaging; audio detection; voltage detection; external alrm; SMD; security exception
Network
Network Port RJ-45 (10/100 Base-T)
SDK and API  Yes
Cyber Security  Video encryption; Firmware encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Network Protocol  IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P
 Interoperability  ONVIF (Profile S/Profile G/Profile T); CGI
 User/Host  20 (Total bandwidth: 64 M)
 Storage  FTP; SFTP; Micro SD card (support max. 256 GB); NAS
 Browser  IE: IE 8 and later
Chrome
Firefox
 Management Software  Smart PSS Lite; DSS; DMSS
 Mobile Client  iOS; Android
Certification
Certifications

CE-LVD: EN62368-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

Port
Audio Input 1 channel (RCA port)
Audio Output 1 channel (RCA port)
Alarm Input 1 channel in: wet contact, 5 mA 3 V–5 VDC
Alarm Output 1 channel out: wet contact, 300 mA 12 VDC
Power
Power Supply 12 VDC (±30%); PoE (802.3af)
Power Consumption

Basic: 3.95 W (12 VDC); 4.95 W (PoE)

Max. (H.265+WDR+ warm light+siren and light active deterrence + intelligence on): 8.7 W (12 VDC); 10.85 W (PoE)

Environment
Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity  ≤95%
Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
Protection IP67
Structure
Casing Metal
Product Dimensions Φ122 mm × 135.2 mm (Φ4.80" × 5.32" )
Net Weight 990 g (2.18 lb)
Gross Weight 1150 g (2.54 lb)
