| Camera |
| Image Sensor |
1/2.7” 6Megapixel progressive CMOS |
| Effective Pixels |
3072(H) x 1728(V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
| Min. Illumination |
0.005 Lux @F1.6 |
| S/N Ratio |
＞56 dB |
| IR Distance |
50 m (164.0 ft) |
| IR On/Off Control |
Auto/Manual |
| IR LEDs Number |
2 |
| Pan/Tilt/Rotation Range |
Pan: 0˚–360˚; Tilt: 0˚–78˚; Rotation: 0˚–360˚ |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm |
| Max. Aperture |
F1.6 |
| Field of View |
2.8 mm: Horizontal 99° × Vertical 53° × Diagonal 115° |
| Iris Type |
Auto |
| Close Focus Distance |
2.8 mm: 0.9 m (3.0 ft) |
| DORI Distance |
Detect: 56.0 m (183.8ft)
Observe: 22.4 m (73.49f)
Recognize: 11.2 m (36.74ft)
Identify: 5.6 m (18.37ft) |
| Professional, intelligent |
| IVS (Perimeter Protection) |
Tripwire; intrusion (Recognition of human and vehicle) |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video |
| Video Compression |
H.265,H.264,H.264B,H.264H,MJPEG (only supported by sub stream) |
| Smart Codec |
Smart H.265+/ Smart H.264+ |
| Video Frame Rate |
Main stream (3072 × 1728@1–20 fps/ 2688 × 1520@1–25/30 fps) Sub stream (704 × 576@1–25 fps/ 704 × 480@1–30 fps) Third stream (1920 × 1080@1–25/30 fps) |
| Stream Capability |
3 streams |
| Resolution |
3072 × 1728; 2688 × 1520; 2560 × 1440; 2304 ×1296; 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (354 × 288/354 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32Kbps ~ 8192Kbps H.265: 12Kbps ~ 8192Kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation |
Yes |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest(RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Image Rotation |
0°/90°/180°/270° Support 90°/270° with 1920 × 1080 resolution and lower.) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; G.726; AAC; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; intensity change; tripwire; intrusion; SMD |
| Network |
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
| Interoperability |
ONVIF(Profile S/Profile G); CGI; P2P; Milestone; Genetec |
| User/Host |
20 (Total bandwidth: 64M.) |
| Edge Storage |
FTP; SFTP; Micro SD Card (support max. 256 G); Dahua Cloud; NAS |
| Browser |
IE: IE8; IE9; IE11 Chrome Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
IOS; Android |
| Certification |
| Certifications |
EN 55032 EN 61000-3-2 EN 61000-3-3 EN 55024 EN 50130-4 EN55035 CE-LVD: EN62368-1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Power |
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
<7.2W |
| Environment |
| Operating Conditions |
-40°C to +60°C (-40°F to +140°F)/less than 95% |
| Storage Temperature |
-40° C to +60° C (-40° F to +140° F) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Metal |
| Dimensions |
Φ106 mm × 93.6 mm (4.17” × 3.69”) |
| Net Weight |
0.55 kg (1.21 lb) |
| Gross Weight |
0.71 kg (1.57 lb) |
