| Camera |
| Image Sensor |
1/2.7”5Megapixel progressive CMOS |
| Effective Pixels |
2592 (H) × 1944 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Minimum Illumination |
0.003 Lux @ F1.0 |
| S/N Ratio |
> 56 dB |
| Illumination Distance |
30 m (98.4 ft) |
| Illuminator On/Off Control |
Auto/ Manual |
| Illuminator Number |
1 (Warm light) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360° |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.0 |
| Field of View |
2.8 mm: Horizontal 103° × Vertical 53° × Diagonal 122°
3.6 mm: Horizontal 81° × Vertical 43° × Diagonal 95° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 1.2 m (3.9 ft)
3.6 mm: 2.1 m (6.9 ft) |
| DORI Distance |
| Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
67.4 m
(221.1 ft)
|
27 m
(88.6 ft)
|
13.5 m
(44.3 ft)
|
6.7 m
(22.0 ft)
|
| 3.6 mm |
80.0 m
(262.5 ft)
|
32.0 m
(105.0 ft)
|
16.0 m
(52.5 ft)
|
8.0 m
(26.2 ft)
|
|
| Professional, intelligent |
| IVS(Perimeter Protection) |
Tripwire; intrusion (support the classification and accurate detection of vehicle and human) |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video |
| Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+/Smart H.264+ |
| Streaming Capability |
3 Streams |
| Resolution |
5M (2592 × 1944); 4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (354 × 288/354 × 240) |
| Frame Rate |
Main stream: 2592 × 1944 @1-20 fps
2688 × 1520 @1-25/30 fps
Sub stream: 704 × 576 @1-25 fps/704 × 480 @ 1-20fps
Third stream: 1920 × 1080 @1-25/30 fps |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps |
| Day/Night |
Color/B/W |
| BLC Mode |
BLC / HLC / WDR(120dB) |
| Scene Self-adaptation (SSA) |
Yes |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detetion |
OFF/ON (4 areas) |
| Region of Interest |
Off / On (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support with 1080p resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
Off / On (4 Areas) |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; safety exception; light alarm; sound alarm (11 built-in sounds and custom voices importing) |
| Network |
| Ethernet |
RJ-45 (10/100Base-T) |
| SDK and API |
Yes |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P |
| User/Host |
20 (Total bandwidth: 80 M) |
| Storage |
FTP; SFTP; Micro SD card (support max. 256 G);NAS |
| Browser |
IE: IE8 and later
Chrome
Firefox
Safari: Safari 12 and later |
| Management Software |
Smart PSS; DSS; DMSS |
| Smart Phone |
IOS, Android |
| Certifications |
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B |
| Port |
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: 5mA 3V–5V DC |
| Alarm Output |
1 channel out: 300mA 12V DC |
| Environment |
| Operating Conditions |
–40°C to +60°C (–40°F to +140°F)/Less than 95% RH |
| Strorage Conditions |
–40°C to +60°C (–40°F to +140°F) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Metal |
| Dimensions |
Φ122.0 mm × 110.9 mm (Φ4.8" × 4.4") |
| Net Weight |
754 g (1.7 lb) |
| Gross Weight |
915 g (2.0 lb) |
| Electrical |
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
Basic power consumption: 2.5W (12V DC); 3.0W (PoE)
Max. power consumption (WDR + H.265 + red and blue lights flashing alternately + warm light + sound alarm): 7.3W (12V DC); 8.0W (PoE) |
